Xi'an Toption 50 L Double Glass Reactor

FOB Reference Price:Get Latest Price
US $1,000-6,000 / Sets | 10 Set/Sets 50L glass reactor (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Automatic Grade:
Semi-Automatic
Type:
Reaction Kettle
Place of Origin:
Shaanxi, China (Mainland)
Brand Name:
TOPTION
Model Number:
TOPT-50L
Voltage:
220V
Power(W):
Xi'an Processing factory for 20 L Double Glass Reactor
Dimension(L*W*H):
double layer glass reactor
Weight:
70kg
Certification:
ISO & CE
Reaction flask(L):
50L
Speed (r/min):
10-680
Stirring torque (1300r/min:
28000g.cm 22000g.cm 15000g.cm
Inside/outside tube dia (mm):
600*550
center 1:
50# double glass reactor
left:
40# Innovation jacketed glass reactor
right:
34# 10 L glass reactor
later:
34# 10 L glass reactor
before:
29# glass reactor
name:
Xi'an Toption 50 L Double Glass Reactor
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
12 Months
Supply Ability
Supply Ability:
3000 Set/Sets per Month industry chemical reactor
Packaging & Delivery
Packaging Details
wooden box packaging industry 50L glass reactor
2.base on your request of Manufacture for Innovation glass reactor
Port
Zhejiang/Shanghai /Tianjin
Lead Time :
3 days unique industry 50L glass reactor

  Xi'an  Toption 50 L  Double Glass Reactor

 Innovation 50L Double Glass Reactor  description

Double glass reactor main sealing parts pure PTFE material, guarantee absolute vacuum system.

Double glass reactor double glass design, inner into reaction menstruum do stirring reaction, interlayer can pass different cold sources (cryoprotectants, hot water or hot oil) do cycle heating or cooling reaction. Setting thermostat conditions, in confined glass reactor, can use require atmospheric or negative pressure conditions conducted stirring response and do reaction solution reflux and distillation is modern Fine Chemical Factory, biopharmaceuticals and new materials

 synthesized ideal test production equipment.



Key Features of unique jacketed glass reactor :



1. Double glass reactor using VVVF, AC Induction Motor. Speed constant, no brush, no sparks, security stable, continuous working.



2. Complete glass reactor adopt GG17 high borosilicate glass production good chemical, physical properties.



3. Glass interlayer Interface communication on hot oil through cycle do Heating Reaction, Tung on cryoprotectants can be hypothermia reaction.



4. Can normal temperature reaction, pass last tap namely quickly will reflect heat away.



5. Decentralization material mouth with flange mouth and PTFE valve, container no dead corner detachable easy solid materials outfeed.



6. 5 reactor lid, large mouth design easy clean standard mouth socket selectable assembly reflux, distillation synthesis device



Technical parameters of  double layer glass reactor



Model

volume

(L)

Motor

power

(W)

Speed

(r/min)



Stirring torque

(1300r/min)

Inside/outside

 tube diameter

(mm)

Reactor vessel cover relevant

 opening size

center

left

right

later

before

TOPT-150L

150

370

10-680



28000g.cm

600*550

50#

40#

34#

34#

29#

TOPT-100L

100

250

22000g.cm

460*500

50#

40#

34#

34#

29#

TOPT-80L

80

250

22000g.cm

460*500

50#

40#

34#

34#

29#

TOPT-50L

50

180

15000g.cm

360*405

50#

40#

34#

34#

29#

TOPT-30L

30

180

15000g.cm

315*360

50#

40#

34#

34#

29#

TOPT-20L

20

120

12000g.cm

315*360

50#

40#

34#

34#

29#

TOPT-10L

10

120

12000.g.cm

245*260

50#

40#

34#

34#

29#

TOPT-5L

5

90

9000.g.cm

200*230

50#

29#

24#

24#

19#

TOPT-3L

3

60

5000.g.cm

200*230

50#

29#

24#

----

19#

TOPT-2L

2

60

5000.g.cm

150*180

50#

29#

24#

----

19#

TOPT-1L

1

40

2400.g.cm

150*180

50#

29#

24#

----

14#





Toption company are professional in glass reactors with more than 10 years, we can provide you more competitive price and best after-sale services, warmly welcome here for quotation.

we also can customize the reactors for you!!
