Topt-10 series mini benchtop vacuum freeze dryer -50- 80 in food

FOB Reference Price:Get Latest Price
US $2,280-2,850 / Set | 1 Set/Sets Topt-10 series mini benchtop vacuum freeze dryer -50- 80 in food (Min. Order)
Supply Ability:
300 Set/Sets per Month Topt-10 series mini benchtop vacuum freeze dryer -50- 80 MOQ : 1
Port:
Shanghai,Shenzhen,Ningbo
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
Vacuum Drying Equipment
Place of Origin:
Shaanxi, China (Mainland)
Brand Name:
TOPTION
Model Number:
TOPT-10D
Voltage:
Customized
Power(W):
970W
Dimension(L*W*H):
565*420*(360+430)mm
Weight:
110kg
Certification:
ISO CE
Warranty:
1 Year
After-sales Service Provided:
Engineers available to service machinery overseas
Application:
drugs, biological products, chemical and food industries
Tray material:
stainless steel
Freeze Drying Area( square meter):
0.08㎡
Cold trap temp:
<-55℃
Vaccum degree:
<10pa
Water-capture capablility:
3~4kg/24h
Material tray diameter:
200mm*3pcs
material volume:
0.08L
Eggplant shaped bottle:
Have
Packaging & Delivery
Packaging Details
Pack of the topt-10 series mini benchtop vacuum freeze dryer -50- 80 in food:
1. Standard wooden case
2. Base on your needs
Delivery Time
In 7-10days after the order

Topt-10 series mini benchtop vacuum freeze dryer -50- 80 in food

Product Description

Description of the topt-10 series mini benchtop vacuum freeze dryer -50- 80 in food
The vacuum freeze drying technology, which is also called sublimation drying,is a technical method that freezes the samples in advance, and then sublimates its moisture in vacuum state. After the freeze drying process, a long term preservation for products is much easier. They can be restored to the original state and maintain their chemical and biological characteristics after being watered.



We have 5 types dryer for series of TOPT-10A , TOPT-10B,TOPT-10C,TOPT-10B,TOPT-10E: Ordinary type, Top press type, Mainfold common type, Mainfold top press type, T- frame type.

Specification:

Model

TOPT-10A

TOPT-10B

TOPT-10C

TOPT-10D

Freeze-drying area

0.12 square meter

0.08  square meter

0.12 square meter

0.08 square meter

Cold trap temp

<-55

Vacuum degree

<10 Pa

Water-capture capability

3~4 Kg/24h

Material tray

D:200mm*4pcs

D:180mm*3pcs

D:200mm*4pcs

D:180mm*3pcs

Power

970w

Dimension

565*420*(360+430)mm

Material volume put in device (10mm)

1.2L

0.8L

1.2L0.8L

D12mm penicillin bottle

920pcs

560pcs

920pcs 560pcs

D16mm penicillin bottle

 480pcs 285pcs 480pcs 285pcs

D22mm penicillin bottle

  260pcs 165pcs 260pcs 165pcs

Eggplant shaped bottle



No



 No

 8 Pcs

100ml/250ml/500ml/1000ml each model 2 pcs

                8 Pcs

100ml/250ml/500ml/1000ml each model 2 pcs



Structure:



Main Features :

1.CFC Free refrigeration
2. LCD display drying curves, English interface
3. Big opening condenser has pre-freeze function
4. low noise compressor, good efficiency,long service life
5. Condenser and operation panel are all stainless steel
6. Drying Chamber with organic glass is safe and visible
7. Shelf and tray are stainless steel
8. Small volume , easy and convenient operation
9. Vertical equipment with caster
10. Nitrogen valve is optional Eutectic point test device is optional
11. Communication interface is optional
12. Cascade refrigeration is optional for -80℃ device

Suggested applications:

Home,laboratory , medicine, pharmacy, biology research, chemical industry and food production ,etc.

Detailed Images



               Stainless stell shelf                      Stainless stell tray              Organic glass cover

 Products show:





The features of goods after vacuum freeze drying:

1.After vacuum freeze drying  goods are easier for long-term preservation.

2.After freezing-drying processing, goods can be restored to the original state.

3. Maintain goods's chemical and biological characteristics after being watered.

Packing & Delivery



Shipping:
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own forward.

Certifications

TOPTION as a professional lab solution provider is specialized in manufacturing and selling freeze dryer, hydrothermal synthesis reactor, photochemical glass reactor , single-layer glass reactor,double-layer glass reactor, three-layer glass reactor,thermostatic equipment, UV glass reactor system, xenon glass reactor, ice maker, ultrasonic instrument, spray dryer, air dryer,extracting device and so on, who are work in chemistry, biology, pharmaceutical, environment analysis, food, academic research, etc. Regardless of the field you work in, we keep striving for the same goal: to provide you with the most suitable solutions & products, to make your research more accurate & efficient.



TOPTION has passed the “ISO9001:2008 Quality Management System”certification and all of our freeze dryer have passed CE certification,the quality can be assured.
Contact us



FAQ

Q: What is your MOQ of the topt-10 series mini benchtop vacuum freeze dryer -50- 80 in food?
A:1 set.



Q: How long is your delivery time of the topt-10 series mini benchtop vacuum freeze dryer -50- 80 in food?
A: Generally it is within 3 working days after receiving the payment if the goods are in stock. Or it is 5-10 working days if the goods are not in stock, depending on order quantity.



Q: How to choose suitable freeze dryer?
A:tell us your work flow and requirements ,then we will recommend you suitable equipment according to yourrequirements, application experience and feedback from our clients.



Q: How to solve the equipment trouble during using ?
A:Please email us about problem with pictures or a small video will be better,we will find the problem and solve it. If broken, we will send you a new free part if in the warranty period.

                For more details about lab instruments, please feel free to contact us~
