Double layer 10L jacketed glass reactor 10l toption

FOB Reference Price:Get Latest Price
US $1,000-9,000 / Set | 1 Set/Sets Double layer 10L jacketed glass reactor 10l toption (Min. Order)
Supply Ability:
500 Set/Sets per Month Double layer 10L jacketed glass reactor 10l toption MOQ:1 set
Port:
Shanghai,Shenzhen,Ningbo
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Automatic Grade:
Automatic
Type:
Reaction Kettle
Place of Origin:
Shaanxi, China (Mainland)
Brand Name:
TOPTION
Model Number:
TOPT-10L
Voltage:
220V
Power(W):
120W
Dimension(L*W*H):
As design
Weight:
TAB
Certification:
CE ISO
Warranty:
One Year
After-sales Service Provided:
Engineers available to service machinery overseas
Stir medium flange:
50
Liquid material inflow:
34# 1L
Condenser:
34#
Temp. measure:
DN15
Stirring paddle:
16mm single layer three blade paddle type
Reactor lid flange:
265mm
Inner diameter of reactor body:
230mm
External diameter:
290mm
Reactor body height:
450mm
Multi function valve:
DN25
Packaging & Delivery
Packaging Details
Pack of the double layer 10L jacketed glass reactor 10l toption:
1.Qualified wooden case for export
2. Base on your needs
Delivery Time
Shipped in 7 days after payment
Product Description

Double layer 10L jacketed glass reactor 10l toption

Toption Jacketed Glass Reactor are available with different options, depending upon their size & their utility. We will glad to assist you in finding a suitable solution for your process requirement.

Below options are available for Jacketed Glass Reactor Unit:
1. Stirrer Drive: Non-Flameproof or Flameproof Motor, 192 RPM with speed regulator.
2. Stirrer material of construction: Glass or PTFE Lined.
3. Stirrer shape: Glass Impeller Stirrer with PTFE Blades, Vortex Stirrer, propeller stirrer & anchor stirrer.
4. Stirring Assembly: Stirring Assembly with bellow seal or with mechanical seal.
5. Supporting Structure: Carbon Steel, Epoxy coated Carbon Steel, Stainless Steel 304 & Stainless Steel 316. All structure are available in Trolley mounted form.
6. Closing Valve: Drain Valve or Flush Bottom Outlet Valve.

This  TOPT-10L Double layer glass reactor /laboratory reactor/jacketed glass reactor adopts GG17 high boron silicon as material ,digital display.And it's high quality has passed CE certification.

Type
TOPT-10L
Glass material
GG17 high boron silicon
Stir medium flange
50
Liquid material inflow
34# 1L
Condenser
34#
Temp. measure
DN15
Multi function valve
DN25
Stirring paddle
¢16mm single layer three blade paddle type
Reactor lid flange
265mm
Inner diameter of reactor body
230mm
External diameter
290mm
Reactor body height
450mm
Power
120w
Rotate speed
50-600rmp

Remark:

1. Custom sevice is welcome here.
2.we also have the match equipment for the glass reactor.
3.If the voltage and plug need to be replaced, pls give clear indication when in contact us.

Key Features of the ouble layer 10L jacketed glass reactor 10l toption:

1. Double glass reactor using VVVF, AC Induction Motor. Speed constant, no brush, no sparks, security staTOPTe, continuous working.
2. Complete glass reactor adopts GG17 high borosilicate glass production good chemical, physical properties.
3. Glass interlayer Interface communication on hot oil through cycle do Heating Reaction, Tung on cryoprotectants can be hypothermia reaction.

4. Can normal temperature reaction, pass last tap namely quickly will reflect heat away.
5. Decentralization material mouth with flange mouth and PTFE valve, container no dead corner detachaTOPTe easy solid materials outfeed.
6. 5 reactor lid, large mouth design easy clean standard mouth socket selectaTOP Te assem TOPT reflux, distillation synthesis device.

Detailed Images




Side discharge valve (standard or preload)

No dead angle, air isolated discharge. Max drift diameter 20mm. Preload discharge valve is able to decrease flask crack risk due to improper over-screw of discharge valve. Customization of TOPTION big capacity glass reactors.

Flask cap (≥10L)

1) Charging valve - pure charge process without gel pollution.
2)Thermometer-direct measurement
3) Condenser - Ball joint connection, easy to assemble, with less vibration.
4) All taper joints upgrade to flanges, no seizure, no damage to glass necks.




Flange quick press ring

One-piece quick clip design. Offer new experience on easy, reliable, and high sealing connection .





PTFE flush discharge valve

No-sample accumulation in valve during operation and discharge. Max drift diameters is 20mm.

Glass reactor lid

Reactor stirring paddle

Worshop  Show
Certifications

TOPTION as a professional lab solution provider is specialized in manufacturing and selling freeze dryer, hydrothermal synthesis reactor, photochemical glass reactor , single-layer glass reactor,double-layer glass reactor, three-layer glass reactor,thermostatic equipment, UV glass reactor system, xenon glass reactor, ice maker, ultrasonic instrument, spray dryer, air dryer,extracting device and so on, who are work in chemistry, biology, pharmaceutical, environment analysis, food, academic research, etc. Regardless of the field you work in, we keep striving for the same goal: to provide you with the most suitable solutions & products, to make your research more accurate & efficient.

TOPTION has passed the “ISO9001:2008 Quality Management System”certification and all of our glass reactor have passed CE certification,the quality can be assured.

Packing & Delivery

Packing:

-Standard wooden case.
-Both neutral and customized packaging can be available.


Shipping:
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own forward.

Our Service

Pre-Sales Service:

1. Inquiry and consulting support.
2. Quick response with detailed quotation
3.Confirm price, quantity, shipment, lead time and payment terms)
4.Make order and sealed PI. (Trade assuranceorder is recommend to new clients for securing payment)

After-Sales Service:
1. One year warranty for the products described here.
2. Beyond the warranty period, product problems can also be solved by our company, but charge component cost and maintenance cost properly.
3.Reliable quality and thoughtful after-sale service: If you encounter problems when using our products, please contact us by telephone or e-mail, we will be ready to provide consulting, maintenance and other services immediately.

Contact us
FAQ

Q: What is your MOQ of the ouble layer 10L jacketed glass reactor 10l toption?

A:1 set.

Q: How long is your delivery time
of the ouble layer 10L jacketed glass reactor 10l toption?

A: Generally it is within 3 working days after receiving the payment if the goods are in stock. Or it is 5-10 working days if the goods are not in stock, depending on order quantity.

Q: How to choose suitable
glass reactor ?

A:tell us your work flow and requirements ,then we will recommend you suitable equipment according to yourrequirements, application experience and feedback from our clients.

Q: How to solve the
glass reactor trouble during using ?
A: Please email us about problem with pictures or a small video will be better,we will find the problem and solve it. If broken, we will send you a new free part if in the warranty period.
