Stock Available Fast Shipping Short Path Molecular Distillation for CBD

  • >=1 Sets
Desalinization Distillation Food Processing Pharmaceutical Processing Other
Model Number:
MDS-6A Distillation Equipment
Lead Time:
Quantity(Sets) 1 - 5 >5
Est. Time(days) 15 Negotiable
Report Suspicious Activity
Quick Details
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, Farms, Retail
Power Source:
Drum Evaporator
Place of Origin:
Shaanxi, China
Brand Name:
220V/ 380V
One Year
After-sales Service Provided:
Field maintenance and repair service
Type of molecular distillation:
MDS-6A Distillation Equipment
Maximum distillation temperature:
300 °C
Evaporation surface:
0.06 m2
Surface of internal condenser:
0.1 m2
Minimum achievable operating pressure:
< 0.001mbar with rotary vane pump and oil
Standard feed vessel:
Standard feed vessel
Charge pump flow capacity L/H:
Material receive method:
Glass receiving flask
Collection tank capacity:
Supply Ability
Supply Ability:
3000 Set/Sets per Year Essential Oil Distillation Equipment
Packaging & Delivery
Packaging Details
with standard wooden box or according to your requirement
Lead Time :
Quantity(Sets) 1 - 5 >5
Est. Time(days) 15 To be negotiated

 Stock Available Fast Shipping Short Path Molecular Distillation for CBD

Product Description

Stock Available Fast Shipping Short Path Molecular Distillation for CBD

Molecular Distillation / Short Path Distillation is a comparatively new separation technology. It can separate liquid-liquid mixture under the temperature that is far lower than boiling point by the difference of mean free path of molecules under high vacuum condition. Such separation is difficult or unable to achieve on normal distillation equipment. Molecular Distillation is especially suitable to separate substance of high boiling point, heat sensitive and easy to be oxidized.

Main application field: Separation process in trades like Food, Pharmaceutical, Fine chemical, Electronic materials, Polymers ( Polyols, fatty acids, Polyphenols compounds, polyurethane, epoxy resin, lactate, glycerol monostearate, flavors and fragrances, fuel oil and paraffin oil), etc.



A complete short path distillation apparatus set should include:
1. Short path evaporator. 2. Heating system.
3. Material charging system. 4. Cooling system.
5. Vacuum system. 6. Material collection unit.

Technical Parameter

 Stock Available Fast Shipping Short Path Molecular Distillation for CBD

ModelCapacity (L/h)Evaporator area (m2)Internal Condenser
Area (m2)
Mixing Motor Power (W)

Liquid Nitrogen

Cold Trap




Remark (A, B, and C models are available for each processing volume, the difference is as follows)
A: charging method: pressure different needle valve adjustment.
B: charging method: high precision gear pump.
C: charging method and material receive method: high precision gear pump.


Key Features

1.All pipeline heat preservation
- All pipeline has jacket heat preservation when the melting point of the material is higher than room temperature, will not congeal in the pipeline.
- Different heat preservation temperature:


2.Can upgrade custom dual condensation cold trap design, to achieve a multi-purpose machine, saving you a set pre-processing equipment

3.A high precision gear pump
Low noise, stable performance, long service life, low ultimate vacuum

4. High quality imported vacuum pump

5.Professional refrigeration heater
Original imported compressor (Copeland), minimum temperature up to -20℃



The application of Stock Available Fast Shipping Short Path Molecular Distillation for CBD

1.Thermal separation of heat sensitive chemical compounds.

2.The purification of organic synthetic material.

3.The separation of effective components from the biological extracting solution.

4.The recycling of industrial waste.

5. Remove toxic substances in the food industry.

6. The organic compounds' decoloring, and eliminate the unusual smell.

7.High precision to remove residual solvent in the chemical compound.


Applied industry

Examples of the species of refined products


Monoglycerides, palm oil, tocopherol, fish oil, rice bran oil, fatty acids and their derivatives, dienoic acid,

Vegetable oil, diglycerides, glutamate, cream, lactic acid, linseed oil, dimer acid,etc.



Acyl chloride, amino acid ester, vitamin E, glucose derivative, terpene ester, natural or synthetic vitamin, beta-carotene, gingerol, capsicum pigment,etc.


Advanced alcohols, glycerides, herbicides, halogenated alkanes, pesticides, silicone oils, waxes, fatty acids, etc.

Plastic industry

Epoxy resin, epoxidated oil, isocyanate, plasticizer, stabilizer, polyether and polyether polyol, etc.

Petroleum industry

Base oil, bright oil, lubricating oil, vaseline, fir oil, residual tar, etc.

Cosmetic industry


Lanolin fatty acid, lanol, including algae, roots of plants, extract of capsicum, high fat ester, turmeric essential oil, dry ginger essential oil, etc.

Related product


Matched Temperature circulator


1.Used to main evaporator*1 set
2.Temp range: RT-300, Power: 3KW, AC 220V


1.Used to feeder and light component’s pipe temperature preservation*1 set
2.Temp range: RT-200, Power: 1.5KW, AC 220V.
Note: The above configuration is for better light-liquidity. If the light phase is viscous material and the fluidity is not good, an additional heater UT-3020 is required for an additional charge.


1.Matched with heavier component’s pipe temperature preservation*1 set
2.Temp range: RT-200, Power: 1.5KW, AC 220V


1.Matched with external condenser*1 set
2.Temp range: -10~200, Power: 3KW, AC 220V

Matched Vacuum

10 pa

No-load vacuum degree 10pa

1 pa

No-load vacuum degree 1pa

0.1 pa

No-load vacuum degree 0.1pa


Packaging & Shipping

Packaging: Wooden case or base on your need

Shipping: by sea, by air, by express door to door service.

Company Information

TOPTION is professional lab solution provider, and all devoted to providing the best solutions & products for global customers, who are work in chemistry, biology, pharmaceutical, environment analysis, food, academic research, etc. Regardless of the field, you work in, we keep striving for the same goal: to provide you with the most suitable solutions & products, to make your research more accurate & efficient.
We believe, only the most excellent quality, most leading technology, most complete solution and most professional service, could make TOPTION mission and vision come true. So we will keep in continual innovation and hard work, to provide you with the best solutions & products, and make you research more accurate and efficient.




Q: What's the processing capacity do you have?
We can offer you 1~3L/H, 5~12L/H, 10~25L/H, 18-30L/H, 20~60L/H.

Q: How long is your delivery time?
A: Usually, delivery time is 30-45 days after receiving your payment.

Q: How about your quality warranty?
A: Normally all TOPTION products are supplied with a warranty of 12 Months from the date of shipment.
We have a very strict inspection, the instruments which you received is high-quality and reliable.
If there’s any error, we’ll provide you the online solution within 12 hours. We’ll provide you the spare parts and the shipping cost totally free.
If the problem was caused by the instrument quality, and cannot be repaired, we’ll ship you the new one.

Q: If we want to customize molecular distillation, is it available?
Sure, we are experienced at this, we have a professional technical team, we can design the drawing according to your requirements and then produce it.




Preferable alternative to short path distillation kits: much shorter residence time, lower processing temperature, capable of continuous operation, and available as a plug-and-play turnkey solution.


Anything you are concerned or confused, please contact us ~
