Rotary Evaporator/vacuum distillation unit

FOB Reference Price:Get Latest Price
US $800-5,000 / Sets | 1 Set/Sets Rotary Evaporator (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
Distillation
Power Source:
Electric
Process:
Rotary
Place of Origin:
Shaanxi, China (Mainland)
Brand Name:
TOPTION
Model Number:
RE Series
Voltage:
220V
Power(W):
1630W
Dimension(L*W*H):
Rotary Evaporator/vacuum distillation unit
Weight:
30 KG
Certification:
ISO& CE
Warranty:
1year
After-sales Service Provided:
Engineers available to service machinery overseas
type:
RE-5203A RE-52CS RE-52A
Down mode:
Hand wheel screw lift/Rocker plate buttons, electric lift
The speed range(rpm):
0-150
Condenser:
Vertical type, double serpentine tube
Rotating bottle maximum capacity (L):
2L 3L
Maximum capacity to collect bottles (L):
2L
Motor power (W):
1000-2000
name:
Rotary Evaporator/vacuum distillation unit
goods:
Rotary Evaporator/vacuum distillation unit
product:
Rotary Evaporator/vacuum distillation unit
Supply Ability
Supply Ability:
3000 Set/Sets per Year rotary evaporator vacuum
Packaging & Delivery
Packaging Details
1.standard wooden packaging for exported Rotary Evaporator/vacuum distillation unit
2.customized by your requests Rotary Evaporator/vacuum distillation unit
Port
Zhejiang /Shanghai /Tianjin
Lead Time :
7-10days after payment

                      Rotary Evaporator/vacuum rotary evaporator

   Rotary Evaporator is the use of vacuum pressure, constant temperature heating conditions, using the rotating bottle constant speed rotation, the formation of large area thin film, high evaporation equipment installations.
     Rotary evaporator is mainly used for pharmaceutical, chemical and bio−pharmaceutical industry concentration, crystallization, drying, separation and dissolution of coal recovery. The principle is: in a vacuum condition, constant temperature heating, to rotate bottles constant rotation, the material in the sidewall formation of large area thin film, high evaporation. Solubilization by high glass condenser vapor cooling, recovery in the collection bottle, greatly improve the efficiency of evaporation, particularly easy to use in high−temperature decomposition of the variability of biological products was concentrated and purified
3Key Features   Rotary Evaporator/vacuum distillation unit
     New floor rotary evaporator, using a large capacity, large diameter rotary evaporation flask, increased evaporation area, in the decompression in the water bath, side spin, side heating, diffusion or evaporation of the solution, a wide range of applications and sample size concentration, drying, extraction, recycling, chemical, pharmaceutical, food, environmental, university research laboratory and industrial mass production of such good equipment

Technical parameters Rotary Evaporator/vacuum distillation unit

Model (RE-)

52A

52AA

5203A

5205

5210A

5220A

5230A

5250A

Rotary flask(L)

0.5-2

3

5

10

20

30

50

Collection flask(L)

1

2

3

5

10+3

10+10

20+10

Motor power(W)

40

60

120

150

180

Rotating speed

(rpm)

3~130

3~110

3~110

5~110

Water bath power(kw)

1.5

2

3

5

5

Evaporate rate(H2O,L/H)

1.2

1.5

2

3.5

5

6

7

Power supply

220-240V 50HZ/60Hz   110-120V 60Hz (Optional)

Bath temp control range(°C)

RT-98

RT-198 (Oil bath optional)

RT-99

RT-198 (Oil bath optional)

Sealing

PTFE sealing

Vacuum degree

0.098Mpa

<133pa/0.098Mpa



  The advantage of  Rotary Evaporator/vacuum distillation unit



1

All the glass parts with high Borosilicate Glass 3.3

2

The voltage can be changed to 110V /60Hz (Standard 220V/50Hz), related

 plug for your country using.

3

With oil bath (RT~180°C)and water bath (RT~100°C) for your choice.

4

Can make special opening on the condenser for testing vapor inlet temp.

5

PT 100 sensor with digital displayer can be added for vapor inlet temperature.

6

Standard exported wooden package to ensure safe delivery.

7

Automatic bath lifting system;

8

Rotary speed between 10 - 110 rpm.

9

All PTFE valves

10

Continuous receiving without interrupt operation.

11

Seal: PTFE Viton gasket vacuum

12

Ultimate Vacuum Level: < 2 mbar.

13

Transparent shield, insulation, energy saving, explosion-proof, splash-proof,

rust-proof, anti-pollution, improve safety performance.

 Christmas Party -

1L, 2L, 3L, 5L, 10L, 20L, 30L,50L Rotary Evaporator can be provided by us. You can choose the rotary evaporator with water bath or oil bath.



Rotary Evaporator with Discharging Valve, easy for collecting material and clean !!!



We believe the quality will not let you down !



Customized Glass Reactor also welcome here !!!



TOPTION---Your top option !



      We believe the quality will not let you down. TOPTION company can custimezed various specifications of glass reactor system, we believe "TOPTION"  will be your "TOP option".



Welcome To Customized Design! Pls don't hesitate to contact us, Welcome!!!
